Most engineering teams reach a point where a CAD file is no longer enough - you need the physical part in hand to check fit, function and feel before committing to production. This guide walks through how to get there: which manufacturing process fits which part, what actually moves cost and lead time, and what to check before sharing a drawing with a shop. For the commercial service overview, start from our prototyping services page.
Table of Contents
At its core, prototyping is the fast production of a physical part from a CAD model, used to validate form, fit and function before a full production run. A service bureau turns your design into a real, testable part using subtractive or formative methods - most often CNC machining, vacuum casting, injection molding and reaction injection molding. The underlying goal is the same in every case: shorten the loop between a design decision and a part you can hold, measure and, if needed, break.
Sourcing further afield is rarely about price alone. Three practical advantages keep overseas bureaus on the shortlist for procurement teams:
· Cost structure: machine-hour and labor rates at comparable tolerance levels are typically far lower than domestic US or EU shops.
· Throughput: many bureaus run extended shifts and return first articles in 3-7 days for machined work.
· Breadth: one supplier can often cover CNC, vacuum casting, injection molding and RIM, which shrinks the vendor list.
A full-service partner usually offers several processes. For plastic parts, CNC machining is the workhorse - the dedicated walkthrough is our CNC plastic prototyping guide. For metal parts, the same shops offer metal prototyping through CNC and vacuum casting. Once volume climbs into the hundreds, rapid injection molding and bridge tooling lower unit cost, and large lightweight enclosures are a fit for reaction injection molding (RIM). Vacuum casting remains the low-tooling route for 10-100 cosmetic or functional copies.
Material choice tracks the test you need to run - structural load, thermal, or visual. A full breakdown by plastic, metal and polymer is in our materials guide. In short: ABS, PC, PEEK, nylon and POM cover most enclosures and fixtures; aluminum, stainless steel, brass and titanium cover strength and heat; urethanes cover soft-touch and overmold looks.
Most engagements follow the same five steps:
1. Submit CAD files (STEP/IGES) with material, quantity and finish requirements.
2. The shop returns a quote with DFM feedback and a lead time.
3. You approve and place a deposit.
4. Parts are machined or molded, inspected and photographed.
5. Parts ship with an inspection report.
Simple machined plastic parts run 3-5 days; metal CNC 5-7 days. Vacuum casting adds mold-making of about 7-12 days. Injection molding adds 1-2 weeks of tooling but pays off above roughly 100 units. If the program is time-critical, our quick-turn prototyping guide explains how to compress the schedule.
Quotes move with material, process, tolerance, surface finish, quantity and secondary operations. To avoid surprises, always ask for an itemized quote that separates machining, finishing and shipping. The mechanics are spelled out in our cost and quoting guide.
Not all bureaus are equal. Evaluate on equipment (3-axis vs 5-axis), QC documentation, communication fluency and IP protection. A practical checklist is in our supplier selection guide.
Reputable suppliers sign NDAs, restrict file access internally and provide inspection reports (CMM, calipers) on request. Ask whether they hold ISO 9001 and whether they can hold your required tolerance before committing. For bridge tooling specifically, our rapid tooling page covers mold options and amortization.
Common sectors include consumer electronics, automotive, medical devices, robotics and industrial equipment. Each carries different certification and material needs, so name your industry early in the conversation.
Q: How much does a prototype cost?
A: Simple machined plastic parts often start at a few tens of dollars per piece in low volume; metal and tight-tolerance jobs cost more. Always request an itemized quote.
Q: How fast can I get a part?
A: Many shops ship first articles in 3-7 days for CNC, and 1-2 weeks once injection tooling is involved, excluding freight.
Q: What files do I need to send?
A: A CAD model in STEP or IGES plus 2D drawings for critical dimensions, material, quantity and finish.
Q: Is my intellectual property safe?
A: Work only with suppliers that sign an NDA and limit file access. Established bureaus routinely handle confidential OEM projects under contract.
Q: Can you do low-volume production, not just prototypes?
A: Yes. Rapid injection molding, rapid tooling and RIM cover bridge production from about 100 to several thousand units.
Q: Which process is right for my part?
A: For tight tolerances and production-grade plastics or metals, CNC machining is the default. For runs of roughly 100-10,000 pieces, injection molding lowers unit cost. For large lightweight enclosures, RIM fits best. Send your CAD and we will recommend the most cost-effective route.
